Cycloidal Gearbox

The RV cycloidal gearbox is a high-precision, heavy-duty reducer designed for robotics, CNC machines, and industrial automation, offering extremely low backlash (<1 arcmin), high torsional rigidity, and long service life. It combines planetary and cycloidal gear stages to deliver high torque transmission in a compact design with excellent positioning accuracy.

Key Features

High Precision: Backlash ≤ 1 arcmin ensures accurate positioning.
High Torque Capacity: Models range from ~137 Nm up to 34,300 Nm depending on size.
Compact & Rigid Design: Roller-based transmission provides high torsional stiffness and shock resistance.
Durability: Designed for continuous heavy-duty operation with long service life.
Efficiency: ≥80% efficiency with low hysteresis loss.
Load Handling: Can withstand emergency stop loads up to 5× rated torque

Applications

Industrial Robots: Commonly used in J1–J3 joints for waist, shoulder, and elbow due to high moment load capacity.
CNC Machines: Rotary tables and spindle drives requiring precision and rigidity.
Automation Systems: Packaging, palletizing, and production lines.
Heavy-Duty Equipment: Solar technology, robotic positioners, and intelligent machinery
CNC machining centers, revolver tool feeders, and rotary table
CNC machine on rotating axis
Scientific instruments
Robotics
Aerospace systems
Transmission systems
Robot positioners

Advantages Over Conventional Gearboxes

Multi-tooth engagement: 30–50% of teeth in contact simultaneously → higher shock load resistance.
Low noise (<65 dB): Suitable for sensitive automation environments.
Compact footprint: Ideal for integrated designs where space is limited.
High reliability: Maintains constant operating behavior over its service life.

Considerations & Trade-offs

Speed Limitation: Larger RV models have relatively low max input speeds (20–60 rpm), making them unsuitable for ultra-high-speed applications.
Cost: Precision reducers are more expensive than standard gearboxes.
Integration: Requires careful motor adapter selection and bearing support for optimal performance.

An RV cycloidal gearbox is a precision reducer widely used in robotics, CNC machinery, and automation systems. It combines a planetary gear stage with a cycloidal gear stage, enabling high torque transmission, minimal backlash, and excellent rigidity in a compact design.

? Core Characteristics

Ultra-low backlash: ≤1 arcmin, ideal for precise positioning.
High torque density: Handles loads from ~100 Nm up to 34,000+ Nm.
Compact & rigid: Roller-based mechanism ensures stiffness and shock resistance.
Durable: Long service life even under continuous heavy-duty operation.
Efficiency: Typically ≥80%, with smooth motion and low noise.

** Zero Backlash:** Cycloidal gearboxes are ideal for applications that demand high precision.

**High Torque Density:** Despite their compact size and robust construction, cycloidal gearboxes deliver significant torque output, making them a superior option for demanding applications.

**Durability:** Designed for complex applications, cycloidal gearboxes are particularly suited for heavy-duty tasks that require both high precision and long-lasting performance.

**Smooth Operation:** These gearboxes are highly effective in robotic arms, enabling precise and consistent movements during operation.

**High Precision and Accuracy:** The micro-movements facilitated by the robotic arm result in smooth and uniform motion.

RV-20E

Cycloidal Gearbox

Request Quote

Enquire Now
