CNC ATC 1.8kw 60k rpm Spindle Motor(GMN)

Model no. ATC-60A

With a rich experience of spindle motors, NK Automations provide High frequency Spindle with precision ultra-high Speed ceramic bearings for précised CNC machine applications like CNC Engraving, CNC bangle engraving, Machining of high precision auto parts, Sheet Cutting and PCB drilling and routing. The spindle is small enough for light machines, but powerful enough to get the job done.

Also it has superior quality, enhanced reliability, smooth motion and balancing stability.

The spindle structure is ATC mechanism, and the tool collet is 3.175mm/6mm

NK spindles with 1.8kw and 60,000 rpm High frequency Spindle with Ultra high speed ceramic bearings (GMN brand) has a robust construction and highly précised and is in accordance with set industrial standards. High overload capabilities and high operation speed range are distinctive features of our Spindle Motors offering exceptional dynamic performance.

Application:

• CNC PCB Drilling Machine

• CNC Sheet Metal Drilling

• CNC Bangle Engraving

• CNC Mobile Tempered Glass Engraving

• CNC Mobile Body and cover Engraving

• CNC Glass Epoxy Engraving

• CNC Denture Machine

• CNC Aluminium Drilling

• CNC Glass grinding

• In Robotics arm for machining automobile Components
